10 Tips For Raspberry Pi-Pico Coding

In this guide we go over 10 power tips for getting yourself going programming the raspberry pi-pico ecosystem. It can be very challenging when you leave the 'pin flipping' python basics!

10 Tips For Raspberry Pi-Pico Coding

1. Get a 'Sacrifice Hub.'  If you are plugging/unplugging your raspberry pi-pico dozens of times - eventually (as I found out) you will damage the port on your laptop / PC.  Instead get a hub with power switches.  Preferably - get a powered one that does not tax your internal motherboard of a laptop.

2. Get a raspberry pi pico-probe.  You can program your raspberry pi-pico without having to mount it / power it / drag your file cycles.   Also - you no longer need to unplug and plug it in all the time.

Raspbery Pi-Pico Conversion to a Pico-Probe Part 1
This simple guide goes over programming your raspberry pi into a pico-probe with hopefully CMSIS-DAP support!

The wiring setup is just this easy.

Some example program commands to get you going with what the output looks like.

  • Note send the .elf file (not the .uf2 file)

3. Make a programming script that calls openocd and programs it.

make -j 4
sudo openocd -f interface/cmsis-dap.cfg -f target/rp2040.cfg -c "adapter speed 500" -c "program ./hello_world.elf verify" -c "shutdown"

If your programming is good you will see:

5. Need some random numbers here is one method to accomplish this on a pico:

 #include "hardware/regs/rosc.h"
#include "hardware/regs/addressmap.h"

typedef unsigned int u16;
  u16 rnd(void)
    u16 k, random=0;
    volatile u16 *rnd_reg=(u16 *)(ROSC_BASE + ROSC_RANDOMBIT_OFFSET);

      random = random << 1;
      random=random + (0x00000001 & (*rnd_reg));
    return random;

6. Need to add object-oriented class programming?. You will need to add the following includes to your source code.  After that .cpp type object-oriented programming will work automatically!

#include <cstdlib>
#include <cstring>
#include <cstdint>

7. Need to inspect your pulses?  Consider a very inexpensive 24 Mhz Analyzer (they start at $14 and work)

8. Need a free pulse plotting software? Install sigrok! It is free software that works with your analyzer.


9. Keep organized - assemble the whole thing into a 'lab-in-a-box.'  It makes for a clean installation:

10. Don't give up!  Don't kid yourself for such small chips there is a LOT of moving parts and pieces.  Consider:

  • A raspberry pi pico has more processing power and speed than a 1980 XT computer by orders of magnitude!
  • Some engineers spend weeks trying to learn the arm eco-system (they just don't want to admit it!)
